COLOR AVAILABLE

SPECIFICATION

ENGINE

Engine Mode 1-cylinder/4-stroke/2-valve
Bore x stroke (mm) ø63.5×62.2
Max.Power 9.5kW/7500 r/min
MAX TORQUE 13.5Nm/6000 R/MIN
Displacement (cc) 197
ignition system EFI

CHASIS

Front suspension Telescopic forks
Front suspension travel (mm) 110
Rear suspension Telescopic coil spring oil damped
Rear suspension travel (mm) 80
Frame type Bassinet type
Fuel capacity (L) 15
Battery 12V6Ah (YTX7A-BS)
FRONT TIRE 110/90-16
REAR TIRE 130/90-15

DIMENSIONS

ground clearence (mm) 135
Overall Length (mm) 2240
Overall Width (mm) 860
Overall Height (mm) 1260
Dry weight (kg) 161
