| MODEL | ||
|---|---|---|
| NAMA | : | MORBIDELLI |
| TIPE | : | C252V |
| ENGINE | ||
| TIPE MESIN | : | V-TWIN CYLINDERS, 8 VALVES MODEL |
| KAPASITAS | : | 249CC |
| DAYA MAKSIMUM | : | 19KW PADA 9000RPM |
| TORSI MAKSIMUM | : | 25NM PADA 5500RPM |
| RASIO KOMPRESI | : | 11.8 : 1 |
| BORE × STROKE | : | 53.5 X 55.4MM |
| TRANSMISSION | ||
| SISTEM PENGGERAK | : | BELT DRIVE |
| KOPLING | : | SLIPPER CLUTCH |
| SUSPENSI DEPAN | : | UPSIDE DOWN |
| SUSPENSI BELAKANG | : | SPRING SHOCK ABSORPTION |
| REM DEPAN/BELAKANG | : | DISC |
| ABS | : | DEPAN DAN BELAKANG |
| TCS | : | DEPAN DAN BELAKANG |
| BAN DEPAN | : | 130/80-16 |
| BAN BELAKANG | : | 140/70-16 |
| RANGKA DAN LENGAN AYUN BELAKANG | : | CRADLE TYPE STEEL FRAME, ALUMINUM ALLOY REAR FORK |
| DIMENSION & WEIGHT | ||
| PANJANG × LEBAR × TINGGI | : | 2202×870×1081MM |
| JARAK SUMBU RODA | : | 1498MM |
| TINGGI JOK | : | 720MM |
| GROUND CLEARANCE | : | 135MM |
| KAPASITAS TANGKI BAHAN BAKAR | : | 15.5L |
| BERAT KOSONG | : | 200KG |
